Description
The EG-WHM 100 AC is a high-performance acoustic wall vent engineered to provide controlled background ventilation in modern residential buildings. Specifically designed for a duct size of only 100mm, it works seamlessly with MEV systems to ensure a constant supply of fresh air while minimising external noise.
Thanks to its acoustic insulation properties (47 dB closed / 42 dB open), it is ideal for homes in noise-sensitive areas, such as near busy roads or rail lines. The vent allows manual adjustment of the effective cross-section, giving occupants flexibility over airflow, while the equivalent area of 2,859 mm² ensures reliable performance
The unit is easy to maintain, with easily accessible grilles. It is available with a choice of external grilles — including square, round, or decorative finishes — in both white or colour options upon request
Key Features
- 100 mm duct connection – Designed for passive wall ventilation with MEV systems.
- Acoustic insulation – 47 dB (closed) / 42 dB (open).
- Manual adjustment – Control effective cross-section and airflow.
- Equivalent area – 2,859 mm² for efficient performance.
- Multiple grille options – Square or decorative external grilles.
- Colour choices – White standard; coloured grilles available on request.
- Easy maintenance – Simple access for cleaning and servicing.
Applications
- Passive wall ventilation in conjunction with MEV systems.
- Residential properties – Bedrooms, living spaces, kitchens, and bathrooms.
- Noise-sensitive environments – Homes near roads, airports, or urban centres.
- Retrofit & new builds – Suitable for modern ventilation compliance.
