Description
The Reneo D180 is a high-performance heat recovery air handling unit designed to provide efficient supply and exhaust ventilation in residential applications such as flats, houses, and cottages. By transferring heat from extracted air to the incoming fresh air, it minimizes heat loss in winter and reduces cooling loads in summer, ensuring year-round indoor comfort.
Key Features
- Airflow Capacity: Up to 158 m³/h at 80 Pa, suitable for small to medium residential spaces.
- Heat Recovery Efficiency: Counter-flow polystyrene heat exchanger with up to 91% efficiency.
- Filtration: standard: G4 (Coarse >60%) filters for both supply and extract air. Optional: F7 (ePM1 60%) fine filter for enhanced filtration of supply air.
- Quiet Operation: Sound pressure level of just 29 dBA at 3m, making it ideal for living areas.
- Energy Efficient: Powered by EC motors with low energy use.
- Compact & Lightweight: EPP casing provides durability, heat insulation, and low weight (12 kg).
Smart Control & Automation
- Integrated S21 automation system with Wi-Fi connectivity.
- Control via the Blauberg Home mobile app (iOS & Android).
- Compatible with Smart Home and BMS (Building Management Systems) via RS-485, Ethernet, and Modbus (RTU/TCP).
- Features include:
- Speed selection and scheduling
- Filter replacement alerts (via timer or pressure switch)
- Full alarm diagnostics in the mobile app
- Automatic bypass for summer cooling
- Boost and fireplace modes
- Freeze protection and optional preheater connection
- Optional CO₂, humidity, VOC, and PM2.5 control sensors
